UVC Series Ultraviolet Coil Purifier for Furnaces 14" UV Lamp 24V/120V

Description

EPA Est. No. 96823-PA-

Germicidal Ultraviolet Light System for Heating and Cooling Systems
HIGH TECH - LSE Lighting®

• Includes 1 UVC HVAC inDuct Slim Unit (compatible with All InDuct Heating and AC Models)
• Includes 1 UVC Light Bulb (GPH357 UV Lamp) - Lamp Length: 14" Long
• High Quality Aluminum Body
• On/Off switch
• LED Indicator Light(s) Verify Proper Operation
• High-quality steel base. Durable lamps with an inside protective coating that ensure constant UV output over the complete lifetime.
• OZONE-FREE: Perfect to be used as an HVAC or furnace UV light. Special lamp glass filters out the 185 nm ozone-forming radiation. Short-wave UV radiation with a peak at 253.7 nm (UVC) is perfect for disinfection purposes.
• Designed to be installed on your HVAC Duct or furnace as a HVAC air purifier system to provide an antimicrobial and antibacterial defense. It helps to keep your air conditioner free of odors and the moldy smell.
• Safe to use: A sign on the bulb indicates that the HVAC UV light produces UVC wavelengths. Always know when air purifier UV bulb is on.
• 254 nm HVAC UV light destroys the DNA of airborne contaminants (bacteria, viruses, mold spores, yeast, and protozoa)
  Do not produce ozone, fumes or other secondary contaminates
• A Must Have Unit for Clear and Pure Air!

Tools Required For Installation

• Drill
• 1/4” Nut Driver
• 3/32” Drill Bit
• 2 ½” Metal Cutting Hole Saw.

Installation Steps:
A. Cut 1 inch hole in your duct (best place to install is above the coil or before return filter)
B. Insert UV lamp inside the hole and attach the 4 screws (included in box)
C. Plug the power cord (6 ft cord included)
